FOCUS ATLAS 8.7 28DI GRY

SPECIFICATION

FRAME

Carbon, disc, C.I.S. integration, press fit BB86, 148x12 mm thru-axle, flat mount 160/160 mm, internal cable routing, Toptube Bag

FORK

Carbon, disc, 110x12 mm thru axle, flat mount 160/160 mm, internal brake cable routing, multiple mounting points

SHIFTER

Shimano GRX ST-RX610, 12-speed

FRONT DERAILLEUR

Shimano GRX FD-RX820

REAR DERAILLEUR

Shimano GRX RD-RX820, 12-speed

CASSETTE

Shimano 105 R7100, 12-speed

CHAIN

Shimano 105 CN-M6100, 12-speed

CRANKSET

Shimano GRX FC-RX610, 12-speed

TRANSMISSION OF DRIVE

vorne: 46/30, hinten: 11-36

CHAINRING

Shimano

BOTTOM BRACKET

Shimano Pressfit Road BB86

HANDLEBAR

FOCUS JD RA85, 31,8 mm, drop: 116 mm, reach: 74 mm, flare: 10°

GRIPS

FOCUS Bartape SL

STEM

FOCUS C.I.S. 2.0 integrated, 31.8 mm, aluminium, with Garmin / Wahoo-Mount

HEADSET

ACROS IS 52/ IS52 (ICR), FOCUS integrated C.I.S.

SADDLE

Prologo Akero

SEATPOST

Lee Chi SP-926, Carbon, 27,2mm, set-back: 0mm

BRAKES FRONT | REAR

Shimano GRX BL-RX610 | Shimano GRX BL-RX610

FRONT BRAKE DISC

160 mm

REAR BRAKE DISC

160 mm

WHEELSET

DT Swiss G1800, 24-622, 12x110 mm / 12x148 mm, 25 mm height

TYRES FRONT | REAR

WTB Riddler, 700 x 45C, folding | WTB Riddler, 700 x 45C, folding

WEIGHT

9.6 kg (-)

PERMISSIBLE SYSTEM WEIGHT

120 kg
